Beskrivning
1.4432, ISO, EN1092-1 Typ35, PN16.
DN
150
Dy
168,3 mm
Dk
212,0 mm
Di
156,3 mm
L
55 mm
h
10 mm
t
2 mm
t1
6 mm
Vikt
2,40 kg
Dimension
168,3 mm
Tryckklass
PN16
holk, svetsring med krage
SVETSRING MED KRAGE 168,3 1.4432 PN16 EN1092-1 TYP35
Det ursprungliga priset var: 1529 kr.1169 krDet nuvarande priset är: 1169 kr. stk
SPARA -24% LagervaraLägsta pris senaste 30 dagarna: 1169 kr / stk
- Varianter
| Artikelnr | DN | Dy | Dk | Di | L | h | t | t1 | Vikt | Dimension | Pris |
|---|---|---|---|---|---|---|---|---|---|---|---|
| BK-RK9156790 | 100 | 114.3 mm | 158.0 mm | 106.3 mm | 52 mm | 10 mm | 2.0 mm | 4 mm | 1.30 kg | 114.3 mm | 599 kr |
| BK-RK9156791 | 125 | 139.7 mm | 188.0 mm | 129.7 mm | 55 mm | 10 mm | 2.0 mm | 5 mm | 1.90 kg | 139.7 mm | 849 kr |
| BK-RK9156792 | 150 | 168.3 mm | 212.0 mm | 156.3 mm | 55 mm | 10 mm | 2 mm | 6 mm | 2.40 kg | 168.3 mm | 1169 kr |
| BK-RK9156793 | 200 | 219.1 mm | 268.0 mm | 207.1 mm | 62 mm | 11 mm | 2.6 mm | 6 mm | 3.90 kg | 219.1 mm | 1989 kr |
| BK-RK9156794 | 250 | 273.0 mm | 320.0 mm | 257.0 mm | 70 mm | 12 mm | 3.2 mm | 8 mm | 5.80 kg | 273.0 mm | 2839 kr |
| BK-RK9156795 | 300 | 323.9 mm | 378.0 mm | 303.9 mm | 78 mm | 14 mm | 4.0 mm | 10 mm | 9.50 kg | 323.9 mm | 4219 kr |
| BK-RK9156787 | 50 | 60.3 mm | 102.0 mm | 54.3 mm | 45 mm | 8 mm | 2 mm | 3 mm | 0.50 kg | 60.3 mm | 249 kr |
| BK-RK9156788 | 65 | 76.1 mm | 122.0 mm | 68.1 mm | 45 mm | 8 mm | 2.0 mm | 3 mm | 0.70 kg | 76.1 mm | 329 kr |
| BK-RK9156789 | 80 | 88.9 mm | 138.0 mm | 80.9 mm | 50 mm | 10 mm | 2.0 mm | 4 mm | 1.00 kg | 88.9 mm | 469 kr |
