Beskrivning
1.4432, Metrisk, EN1092-1 Typ35, PN16.
DN
350
Dk
430,0 mm
Dks
370 mm
L
70 mm
h
15 mm
t
4,5 mm
t1
11 mm
Vikt
15,20 kg
Tryckklass
PN16
holk, svetsring med krage,
SVETSRING MED KRAGE 350 1.4432 PN16 EN1092-1 TYP35M
Det ursprungliga priset var: 8649 kr.7019 krDet nuvarande priset är: 7019 kr. stk
SPARA -19% Beställningsvara (prel 10-15 vardagar)Lägsta pris senaste 30 dagarna: 7019 kr / stk
- Varianter
| Artikelnr | DN | Dk | Dks | L | h | t | t1 | Vikt | Pris |
|---|---|---|---|---|---|---|---|---|---|
| BK-RK9156735 | 100 | 158.0 mm | 108 mm | 50 mm | 10 mm | 3 mm | 4 mm | 1.30 kg | 619 kr |
| BK-RK9156736 | 125 | 188.0 mm | 135 mm | 50 mm | 10 mm | 3 mm | 5 mm | 1.90 kg | 879 kr |
| BK-RK9156737 | 150 | 212.0 mm | 160 mm | 50 mm | 10 mm | 3 mm | 5 mm | 2.40 kg | 1199 kr |
| BK-RK9156738 | 200 | 268.0 mm | 214 mm | 65 mm | 10 mm | 3.0 mm | 7 mm | 3.50 kg | 1879 kr |
| BK-RK9156739 | 250 | 320.0 mm | 266 mm | 65 mm | 12 mm | 3.5 mm | 10 mm | 5.80 kg | 2679 kr |
| BK-RK9156740 | 300 | 370.0 mm | 320 mm | 65 mm | 12 mm | 4.0 mm | 10 mm | 9.50 kg | 4379 kr |
| BK-RK9156741 | 350 | 430.0 mm | 370 mm | 70 mm | 15 mm | 4.5 mm | 11 mm | 15.20 kg | 7019 kr |
| BK-RK9156742 | 400 | 482.0 mm | 424 mm | 80 mm | 15 mm | 5.0 mm | 12 mm | 18.70 kg | 9579 kr |
| BK-RK9156732 | 50 | 102.0 mm | 54 mm | 45 mm | 8 mm | 2 mm | 2 mm | 0.53 kg | 259 kr |
| BK-RK9156744 | 500 | 585.0 mm | 524 mm | 95 mm | 18 mm | 5 mm | 12 mm | 29.10 kg | 15169 kr |
| BK-RK9156733 | 65 | 122.0 mm | 71 mm | 45 mm | 10 mm | 2.5 mm | 3 mm | 0.70 kg | 339 kr |
| BK-RK9156734 | 80 | 138.0 mm | 86 mm | 50 mm | 10 mm | 3 mm | 3 mm | 1.00 kg | 479 kr |
